History of the Field Museum Fossil Halls – Part 2

Start with History of the Field Museum Fossil Halls – Part 1.

Where we left off, the fossil exhibits in Halls 37 and 38 at the Field Museum of Natural History had gone for decades without more than piecemeal improvements. In the meantime, the field of paleontology – and our understanding of dinosaurs in particular – had progressed by leaps and bounds. What’s more, standards for natural history exhibits had changed. Cases of specimens with esoteric labels written by curators past were no longer enough. Visitors expected exhibits that were relatable and accessible for children as well as interested adults, and multimedia and interactive elements had become standard. This combined with ever-growing public interest in all things prehistoric gave Field Museum staff serious incentive to start with a clean slate.

Phase III: Life Over Time

The end of the old fossil halls came not with a bang but with a whimper. In 1990, specimens started disappearing and areas were roped off without warning. Hundreds of specimens were relocated to Halls 25, 26, and 29 on the other side of the second floor, where they would be part of the exhaustive new exhibit “Life Over Time.” Meanwhile, Halls 37 and 38 became the home of the pacific islands exhibit and Ruatepupuke II, the Maori Meeting House.

life over time albertosaurus remount

Remounted Daspletosaurus in Life Over Time, then labeled Albertosaurus. Photo courtesy of the Field Museum Photo Archives.

As the name suggests, Life Over Time was a chronological journey through the history of life, from its origins around four billion years ago up to the last ice ages. Paleobotanist Peter Crane chaired the Geology Department during the development period, and geologist and children’s education specialist Eric Gyllenhaall oversaw the contractors and in-house staff that created the the exhibit itself. In total, the project took five years and cost $7 million.

Gyllenhaal and the rest of the team conceived of Life Over Time as a directed experience. The space was shaped like a U, with switch-backing corridors flanking a more open dinosaur section in the middle. With the exception of a shortcut between the Carboniferous and the Mesozoic, visitors had no choice but to walk through the exhibit chronologically, viewing the displays in the order the designers mandated. Since visitors tend to be more focused and more likely to read signs early in the exhibit, the designers deliberately used the introductory rooms to cover the most unfamiliar concepts. Displays on the origins of life and the evolution of aerobic respiration made up the “homework” part of the exhibit. After that, visitors were set free in the Mesozoic section, where open sight lines allowed people to choose what they wished to view, and in what order. This served as a reward for putting up with the more challenging material early on. Ultimately, what set Life Over Time apart from its predecessors was the focus on ideas rather than specimens. The fossils were meant to illustrate broader concepts like adaptation, extinction, and biogeography, and were in some ways subordinate to the hands-on activities and multimedia displays.

new triceratops

This cast of the AMNH Triceratops was a new addition to Life Over Time. Photo by Gary Todd.

Apatosaurus

In Life Over Time, visitors circled the dinosaurs on an elevated ramp before visiting them at ground level. Photo by Erik Peterson.

The process of developing Life Over Time was an occasionally tense give-and-take between the research staff (who traditionally had the last word on exhibit content) and the administrators, exhibit specialists, and educators (who had greater influence this time around). Looking back, it would seem that the curators lost more of these fights than they won. Life Over Time ended up with a decidedly kitschy tone, and was full of overtly silly elements. The exhibit entrance featured carnival-style banners advertising “Primordial Ooze” and “Dunkleosteus: Jaws of Death.” Further on, a mannequin dressed as a game show host invited visitors to spin the “Wheel of Adaptation.” There were Dial-A-Dinosaur phones, which visitors could pick up and listen to first-person accounts of life as a dinosaur. An animatronic puppet show explained the switch from aerobic to anaerobic life. Video “weather reports” with CBS anchor Bill Kurtis updated visitors on climate change over time. There was even a ridable trilobite on a spring.

This carnival-like atmosphere is particularly distinctive when compared to the present fossil halls at the American Museum of Natural History, which were developed at the same time. AMNH project director Lowell Dingus rejected contemporary trends in exhibit design, which, in his view, were pitched to “the lowest common denominator of visitor intellect.” Wishing to challenge audiences to think about fossils the way scientists do, Dingus created a phylogeny-based exhibit that emphasized empiricism and rigorous anatomical analysis over idle speculation. While it was certainly not devoid of informative content, Life Over Time was designed for a much younger audience, with particular attention paid to the under-five set. This marked contrast between the New York and Chicago exhibits speaks volumes about the differing influence of the scientific staff at the two museums, as well as the institutions’ overall priorities at the time.

Permian cluster

Postcard of the pelycosaur cluster in Life Over Time. These specimens were donated by the University of Chicago in the 1960s.

Happily, the Field Museum didn’t opt to replace its authentic mounted fossil skeletons with the roaring robots that were in vogue at the time. The classic fossil mounts were restored and rebuilt by Prehistoric Animal Structures, Inc., a Canadian company headed by Gilles Danis. A biologist by training and a veteran of the Royal Tyrell Museum, Danis led the process of disassembling, cleaning, and remaking the most significant mounts. The ApatosaurusDaspletosaurus, and Megathierum were all given more accurate and active poses: the Daspletosaurus now crouched over its Lambeosaurus prey with its tail held aloft, while the giant sloth stretched to its full height against a replica tree. Although it was completely rebuilt, the Apatosaurus retained its dragging tail in the new exhibit – an unusual choice for a 1990s reconstruction.

In addition to the classic mounts, Life Over Time featured a partial Parasaurolophus and a new cast of the AMNH Triceratops. The most substantial addition was a complete Brachiosaurus reconstruction. This 40 foot tall mount combined casts taken from the material Elmer Riggs collected at the turn of the century with sculpted elements prepared by Stephen Godfry.  Far too large for the second floor exhibit halls, the Brachiosaurus earned a place of honor in the central Stanley Field Hall. In order to comply with the fire code while allowing visitors to walk under the towering sauropod,  the torso was extended by adding two extra dorsal vertebrae (for a total of twelve). In an amusing twist, newer research shows that this vertebrae count – and the mount’s stretch limo proportions – is probably correct.

main hall brachiosaurus

The Brachiosaurus skeleton was tall enough to look over the second floor mezzanine. Source

Life Over Time opened to the public in June 1994 (the Brachiosaurus had been on display for a year prior). Nevertheless, it was the shortest-lived iteration of the Field Museum’s fossil displays, closing down after only ten years. Why didn’t it last? For one thing, the numerous interactive elements suffered more wear and tear than expected, and they broke frequently. Meanwhile, in-house evaluations showed that the exhibit’s intended messages were not coming across to most visitors. For example, Asma recalls a child frantically spinning the Wheel of Adaptation with all his might, completely oblivious to the information the display was meant to convey. Unfortunately, an interactive exhibit is not necessarily an educational one, and it can be very difficult to create a learning experience that accomplishes both goals.

Phase IV: Evolving Planet

There was one more reason the Field Museum needed to revisit its fossil displays: the sudden acquisition of Sue the Tyrannosaurus in 1997. The story of the four-way legal battle that preceded this has been told often (although not always fairly), so suffice it to say that few came out of that fight unscathed. The Field Museum entered the picture when landowner Maurice Williams, to whom the courts had awarded ownership of Sue, announced that the fossils would be placed on the auction block. Paleontologists initially worried that the priceless specimen would disappear into the hands of a wealthy collector, or end up in a crass display at a Las Vegas casino. Those fears were put to rest when the Field Museum won Sue with financial backing from McDonald’s and Disney. Including the auctioneer’s commission, the price was an astounding $8.36 million.

susan

Some obscure theropod. Photo by the author.

The Field Museum committed to a summer 2000 unveiling of Sue’s mounted skeleton. However, most of the bones was still buried in rock and plaster. The fossils had to be prepared and stabilized before they could be studied, and they had to be studied before they could be mounted. Most of this work was done on-site, in view of the public. The armature itself was created by Phil Fraley Productions, the same exhibit company that rebuilt the AMNH Tyrannosaurus. Field Museum administrators decided that Sue would replace the Brachiosaurus in the Stanley Field Hall, even though the sauropod had only been on display for seven years. According to Exhibit Project Manager Janet Hong, Sue was such a monumental exhibit that it really deserved pride of place. Meanwhile, the Brachiosaurus was relocated to O’Hare International Airport, while a weather-proof duplicate was placed outside the museum.

Sue was revealed to the public on May 17, 2000 with the literal raising of a curtain. A week-long series of celebrations and press junkets introduced Sue to Chicago, and it has been one of the city’s biggest attractions every since. All the publicity paid off, at least in the short term: Field Museum attendance soared that year from 1.6 million to 2.4 million. 16 years later, Sue’s new identity as a Chicago landmark seems to have all but eclipsed the legal dispute that was its original source of fame. Hong likens Sue to Chicago’s David, and even former Field Museum President John McCarter feels that he underestimated what a force Sue would be for the city.

Map of Evolving Planet. Source

Map of Evolving Planet. Source

The acquisition of Sue created a strong public association between the Field Museum and dinosaur research. This was ironic, because while the museum had hosted a talented array of paleontologists over the years, it had never employed a dinosaur specialist. Even Elmer Riggs, who collected the museum’s iconic sauropods at the turn of the century, was more interested in mammal evolution. In 2001, the Field Museum began a concerted effort to expand its vertebrate paleontology program, and make a name for itself as a hub for dinosaur science. Among the new hires were fossil preparator Akiko Shinya and paleontologist Peter Makovicky, who immediately began organizing expeditions to grow the museum’s collection.

The new emphasis on paleontology research brought greater expectations for the Field Museum’s interpretive efforts, and Life Over Time wasn’t doing the job. The initial plan was to merely refresh the decade-old exhibits, but ambitions grew and the renovation snowballed into something much more substantial. Project Manager Todd Tubutis and Content Specialist Richard Kissel spent five years overseeing the development of Life Over Time’s replacement, eventually titled “Evolving Planet.”

Once we reach the Permian, the fossils can start to speak for themselves. Photo by the author.

Each section of Evolving Planet is differentiated by its own color palate and ambient audio. In the Permian, olive green walls and signs are accompanied by the sounds of a windswept desert. Photo by the author.

w

Yes, of course this series needs another picture of the Apatosaurus. Photo by the author.

While the new exhibit uses the same space and directed, U-shaped layout as its predecessor, the end result is virtually unrecognizable. The hokey parts of Life Over Time are gone, replaced by all-new signs, labels, and interactives. New specimens include original Parasaurolophus, Rapetosaurus, and Arctodus mounts, plus casts of Stegosaurus and Deinonychus, all prepared by Research Casting International. An entire room is dedicated to fossils from Utah’s Green River Formation, acquired on a recent Field Museum collecting expedition. Phlesh Bubble Studios provided a panoramic CGI reconstruction of the Burgess Shale Fauna, while Karen Carr produced 150 original paintings to supplement the classic Charles Knight murals. These, in turn, were restored by Parma Conservation and are contextualized as the historic masterpieces they are. Nevertheless, Evolving Planet has a few holdovers from Life Over Time. The existing dinosaur mounts were not moved or changed, and major set pieces like the walk-through Carboniferous swamp diorama remain in place.

Timeline moments and consistent iconography

Repeating iconography keeps visitors engaged in story of life on Earth. Photo by the author.

Karen Carr art fills in gaps in classic Knight pieces

New artwork by Karen Carr fills gaps left by the classic Charles Knight murals. Photo by the author.

The interpretation in Evolving Planet arose from three main objectives. First, the exhibit needed to highlight the Field Museum’s own collections and the work of its in-house research staff. Second, it had to contextualize Sue and the environment they lived in. Finally, it had to effectively explain the process of evolution, and the evidence for it. Life Over Time had faltered here, and with the influence of the anti-science lobby increasing, it was crucial to get it right. Tubutis and Kissel accomplished this in part by facilitating closer collaboration between the exhibit designers and research staff. Evolving Planet weaves the evidence for evolution into all aspects of the displays. The first thing visitors see is the thesis of the exhibit – “everything that has ever lived is connected through and is the result of evolution” – printed on an otherwise blank wall. Moving forward, visitors learn how evolution via natural selection works, and how we know. Along the way, common misconceptions, such as the idea that lineages improve over time, or that evolution is “just a theory”, are proactively addressed and corrected.

The visual design of Evolving Planet deserves particular mention. The new exhibit subtly but effectively uses repeating iconography to guide visitors through the story being told. Every geological period is associated with a specific color scheme and soundscape, making visitors’ progression from one stage to another obvious and distinct. “Timeline Moments” at the beginning of each section update visitors on their progress, and ensure that they expect to see something new and different up ahead. Special symbols remind visitors of recurring themes, such as mass extinctions (or even the repeated evolution of saber-teeth). Lastly, variations in font and text size are cleverly employed to call attention to key words and phrases.

old riggs mounts, new sloth, charles knight

A new pose and context for Megatherium, along with historic Riggs mounts and Knight artwork. Photo by the author.

Evolving Planet opened on March 10, 2006. A decade later, this award-winning exhibition remains a favorite with scientists and educators alike. As Cleveland Museum of Natural History Educator Ashley Hall explains:

Evolving Planet is my all-time favorite museum exhibit. It is not only rich with some of the world’s best known fossil specimens, but provides label copy for visitors of all learning levels. You can visit multiple times and still learn something new. Museums provide visitors with unique settings for learning, and it is a museum’s job not to short-change, dumb down, or simplify information. Evolving Planet hits the nail on the head.

From its clear-as-day thesis to its poignant finish (a counter showing the number of species going extinct daily), Evolving Planet is ambitious but uncommonly relatable. It places familiar dinosaurs and mammoths in a broader evolutionary context, introducing visitors to the true breadth of deep time. And yet, the exhibit is also remarkable for its restraint. It doesn’t overwhelm casual visitors with specimens and facts, but instead sticks to a handful of broadly-applicable themes.

The Field Museum’s paleontology program spent its early years playing catch-up to peer institutions. While other American natural history museums were conducting yearly fossil-collecting expeditions and building collections of one-of-a-kind specimens, the Field Museum’s founding paleontologists struggled for basic resources and recognition within their institution. Today, the department’s public showroom is what Kissell describes as “one of, if not the, most comprehensive explanations of the history of life on Earth in any museum.” It would seem that the Field Museum has found its voice in the pantheon of great natural history museums.

Many thanks to Ashley Hall, Olivier Rieppel, Bill Simpson, and Devin Myers for sharing their time, expertise, and experiences when I was writing this post. Any factual errors are, of course, my own.

References

Asma, S.T. 2001. Stuffed Animals and Pickled Heads: The Culture and Evolution of Natural History Museums. New York, NY: Oxford University Press.

Dingus, L. 1996. Next of Kin: Great Fossils at the American Museum of Natural History. New York, NY: Rizzoli International Publications, Inc.

Fiffer, S. 2000. Tyrannosaurus Sue: The Extraordinary Saga of the Largest, Most Fought Over T. rex ever Found. New York, NY: W.H. Freeman and Company.

Glut, D.F. 2001. Remembering the Field Museum’s Hall 38. Jurassic Classics: A Collection of Saurian Essays and Mesozoic Musings. Jefferson, NC: McFarland.

Lee, B.M. 2005. The Business of Dinosaurs: The Chicago Field Museum’s Nonprofit Enterprise. Unpublished thesis, George Washington University.

Lelièvre, M A. 2006. Evolving Planet: Constructing the Culture of Science at Chicago’s Field Museum. Anthropologica 48: 2: 293-296.

Milner, R. 2012. Charles R. Knight: The Artist Who Saw Through Time. New York, NY: Abrams.

Tubitis, T.J. 2005. Revitalizing Life Over Time: A New Look for a Very Old Topic. In the Field 76: 2: 18.

1 Comment

Filed under dinosaurs, education, exhibits, FMNH, fossil mounts, history of science, paleoart

History of the Field Museum Fossil Halls – Part 1

The Field Museum of Natural History (variously known as the Field Colombian Museum and the Chicago Museum of Natural History) was founded by wealthy philanthropists in the wake of the 1893 World’s Columbian Exposition in Chicago. It has since expanded into one of the largest natural history museums in the world, a destination attraction and a hub for ongoing research. What follows is a summary of the historic paleontology exhibits at the Field Museum – when and how they expanded and changed, when major specimens were added, and who spearheaded these efforts.

As with my previous overviews of fossil exhibits at AMNH and NMNH, please note that I will not be discussing field expeditions or research by museum staff in any detail, as these topics are well-explored elsewhere (see Paul Brinkman’s extensive work, for starters). My primary interest here is in the public-facing exhibits, and the people who created them.

Phase I: The Field Columbian Museum

The World’s Columbian Exposition was held in Chicago in 1893, principally as a celebration of the 400th anniversary of Christopher Columbus’s arrival in the Americas. Lasting six months and attended by 27 million people, the Exposition was monumental in size and scope. Years before it even opened, there was talk about using the Exposition displays to seed a new museum, which would rival the great natural history museums in New York and Washington, DC. Eager to establish an enduring cultural attraction in their city, a group of wealthy Chicagoans – including Marshall Field, who donated an unprecedented $1 million – contributed the necessary funds to buy up many of the Exposition’s exhibits and found the Field Columbian Museum.

As the largest and most elegant of the 200 temporary buildings constructed for the Exposition, the Palace of Fine Arts became the Field Museum’s home. Frederick Skiff served as the first director, acting as an intermediary between the board of trustees and the new curatorial staff, who would manage the collections and assemble the exhibits. Skiff hired geologist Oliver Farrington to curate the earth science collections, a diverse mix of minerals, gems, meteorites, fossils, and fabricated displays purchased from the Henry Ward Natural Sciences Establishment. With thousands of specimens to catalog, Farrington was soon overwhelmed. He repeatedly asked Skiff to hire a paleontology specialist to support him, but the board (composed of the businessmen who founded the museum) was uninterested in paying more salaries or acquiring new specimens.

fossils

The model icthyosaur and thousands of fossils in cases were among the specimens purchased from the Ward Natural Sciences Establishment after the World’s Columbian Exposition. Image courtesy of the Field Museum Photo Archives.

When the Field Columbian Museum opened on June 2nd, 1894, most the 5,000-piece fossil collection was on public display. In addition to the cases of as-yet unlabled invertebrates, plants, and other small fossils, the exhibit included several large reconstructions of prehistoric animals. As of opening day, a life reconstruction of a mammoth stood in the west court, while skeletons of MegalocerosScistopleurum, MegatheriumHadrosaurus, and a uintathere stood in halls 35 and 36. With the exception of the Megaloceros, these were all replicas of mounts from other institutions. The Hadrosaurus in particular was woefully outdated, considered by contemporary scholars to have “long since ceased to have any value except as a historic attempt” (Beecher 1901).

After completing his catalog of the earth science collections in 1896, Farrington continued to lobby for a dedicated staff paleontologist. The board paid no attention until 1897, when the American Museum of Natural History and the Carnegie Museum of Natural History announced ambitious plans to scour the western interior for fossils. So began what Brinkman calls the second Jurassic dinosaur rush – a frenzied race among leading American museums to be the first to collect and mount a sauropod dinosaur. Not wanting to be left behind by peer institutions, the trustees approved the conditional hiring of Elmer Riggs to collect dinosaurs for the Field Museum.

Hadrosaurus cast on display at the Field Museum. Field Museum Photo Archives.

Hadrosaurus stands among other fossil casts in the Field Columbian Museum. Image courtesy of the Field Museum Photo Archives.

Riggs and his classmate Barnum Brown cut their teeth in paleontology while studying under Samuel Wendell Williston at the University of Kansas. The two young men took part in an AMNH collecting expedition in 1896. Brown, who had quit his studies to work for the museum, quickly became a favorite at AMNH. Concerned about his own future, Riggs sent an unsolicited letter to Frederick Skiff, offering his skills as a fossil collector and preparator. The letter crossed Skiff’s desk at an opportune time, and in the summer of 1898 Riggs was paid a small stipend for a trial collecting trip with Farrington. The expedition was a success, and Riggs was hired as an Assistant Curator before the end of the year.

Riggs’ first three collecting seasons with the Field Museum were enormously successful. In addition to the holotype of Brachiosaurus, at the time the largest known dinosaur, Riggs collected a very-well-preserved back end of an Apatosaurus near Fruita, Colorado. Nevertheless, AMNH won the sauropod race when they completed their composite “Brontosaurus” mount in 1905. The Carnegie Museum had a Diplodocus on display in 1907, and was busy cranking out casts for European heads of state. While Riggs’ Apatosaurus was more complete than any single specimen the other museums had recovered, it was still only half a dinosaur. Riggs and Farrington repeatedly lobbied the board for funding to find more sauropod material with which to complete the skeleton, but the trustees had moved on to other things.

Riggs' Apatosaurus mount stood unfinished from 1908-1958. Photo from the Field Museum Library.

Riggs’ Apatosaurus mount stood unfinished from 1908-1958. Image courtesy of the Field Museum Photo Archives.

Plans were afoot to move the Field Museum to a new lakefront campus. However, when legal issues halted progress on the new building, Riggs was granted permission to mount the partial Apatosaurus in hall 35. The plaster casts previously displayed in this space were discarded, and unfortunately are now lost to history. A gas furnace was installed on the museum grounds, which Riggs and his small team used to shape massive steel I-beams for use in the armature. The teetering sauropod hindquarters was unveiled in 1908, but if Riggs hoped that the museum administrators would want to complete the mount once they saw how absurd the incomplete skeleton looked, he was out of luck.

Indeed, the years that followed were among the most frustrating of Riggs’ career. He received no funding to collect fossils after 1910, and could only look on enviously at the thriving paleontology research and exhibit programs at AMNH and the Carnegie Museum. The institutions in New York and Pittsburgh were headed by paleontologists, and bankrolled by wealthy fossil enthusiasts like J.P. Morgan and Andrew Carnegie. By comparison, the Field Museum was controlled by trustees with seemingly little interest in paleontology. Already paid less than the museum’s other curators, Farrington and Riggs were left with meager resources and little to do until the 1920s.

Phase II: Halls 37 and 38

The Palace of Fine Arts was intended to last six months, and after ten years it was in dire shape. The roof leaked constantly, putting exhibits and collections in danger, and fences had to be placed around the perimeter to protect visitors from falling brick. Before his death in 1906, Marshall Field worked with architect Daniel Burnham to design a new home for the museum. It took years to settle disputes over where to place the building, but ground was eventually broken off Lake Shore Drive in 1915. Completed in 1920, the new Field Museum of Natural History was a gleaming marble fortress, decorated inside and out with intricate neoclassical reliefs and statuary.

hall 37

In the spirit of a classic cabinet of curiosity, some of the cases in Hall 37 contained over a thousand specimens apiece. Source

Exhibits and collections were transported by rail car, often without being removed from their display cases. Earth science exhibits found a new home on the west side of the upper level. Hall 37, an east-west facing gallery accessible directly off the west mezzanine, housed invertebrate and plant fossils. Hall 38, running north to south against the far west side of the building, contained vertebrate fossils. Although it was colloquially known as the “dinosaur hall”, this space never contained many dinosaurs. In the 1920s, the only dinosaurs to be found were the half-Apatosaurus, a Triceratops skull, an articulated “Morosaurus” (Camarasaurus) limb, and parts of Brachiosaurus. The bulk of the specimens on display were Cenozoic mammals, including horses, rhinos, camelids, and a mammoth and mastodon. There was also a life-sized “coal swamp” diorama behind a glass barrier, with large model insects suspended in flight.

This comparatively modest exhibit was expanded significantly between 1922 and 1927, when Elmer Riggs was once again able to collect fossils in the field. Thanks to a bequest from Marshall Field’s grandson, Riggs traveled to Alberta, Argentina, and Bolivia, securing many unique specimens along the way. These included several new species, like the marsupial cat Thylacosmilus and the predatory bird Andalgalornis. A colossal Megatherium Riggs recovered in Argentina was immediately mounted for display, and became one of the most memorable elements of Hall 38.

hall 38

A postcard of the partial Apatosaurus at the south end of Hall 38. Image courtesy of the Field Museum Photo Archives.

A postcard of the north end of Hall 38, featuring a South American giant sloth and other Cenozoic mammals.

Megatherium at the north end of Hall 38. Image courtesy of the Field Museum Photo Archives.

Hall 38 also boasted a spectacular set of murals by Charles Knight. The undisputed master of paleontological reconstructions and wildlife art, Knight had a long working relationship with Henry Osborn, president of AMNH. Osborn had commissioned Knight to create many large and small paintings for his museum’s fossil exhibits, but the two frequently argued over Knight’s remuneration. For years, Osborn and Knight discussed a series of immense wall canvases illustrating the entire history of life. Osborn could never get the money together, however, and Knight refused to produce any concept sketches for fear that they would be turned over to a less-skilled artist. In 1926, the Field Museum’s board of trustees asked for a meeting with Knight about an identical project for their new fossil hall. The initial discussion did not go well, and Knight walked out when the trustees started making “suggestions” about the content, color, and composition of the proposed artwork. Knight was very talented, but also very particular. He gladly accepted anatomical expertise from scientists but would not suffer meddling with the artistic aspects of his work. Fortunately for both parties, Knight’s daughter/manager Lucy intervened, securing her father the biggest commission of his career.

Knight completed 28 murals for the Field Museum, the largest of them measuring 25 feet long and nine feet high. Subjects ranged from the Proterozoic primordial soup to an iconic standoff between Tyrannosaurus and Triceratops. These images were not only painstakingly researched reconstructions based on the latest fossil evidence, they were (and still are) gorgeous works of art in their own right. With Knight’s murals in place, the Field Museum finally had a world-class paleontology exhibit.

hall 38 mastodon

The mastodon in Hall 38, with fossil horses visible beyond. Image courtesy of the Field Museum Photo Archives.

Gorgo in Stanley Field Hall. Photo courtesy of Field Museum Photo Archives.

Gorgosaurus” in the Stanley Field Hall. Photo courtesy of Field Museum Photo Archives.

Riggs retired in 1942, leaving paleontology at the Field Museum to the next generation, among them Eugene Richardson, Brian Patterson, and Orville Gilpin. In 1951, Richardson oversaw a thorough modernization of Hall 37. The number of specimens on display was drastically reduced, making room for more accessible explanations of the fossils and ten new dioramas of Paleozoic marine life. The resulting exhibit was one of the most comprehensive displays of fossil invertebrates in the world.

Although virtually no dinosaur research was done at the Field Museum between 1910 and the late 1990s, the 1950s saw the acquisition of two significant specimens for the benefit of the visiting public. In 1956, preparator Orville Gilpin assembled a Daspletosaurus (then called Gorgosaurus) for the central Stanley Field Hall. The skeleton was a surplus specimen from Barnum Brown’s years collecting along Alberta’s Red Deer River, and trustee Louis Ware spearheaded the effort to buy it from AMNH. Since the Daspletosaurus was acquired explicitly for display, Gilpin opted to skewer and otherwise permanently damage many of bones for the sake of an unobstructed, free-standing mount. In the mid 20th century, dinosaur fossils were thought of as display pieces first, and irreplaceable specimens second.

apatosaurus revised

The newly-finished Apatosaurus serves as a backdrop for an educational video shoot. Source

Two years after installing the Daspletosaurus, Gilpin finally completed Riggs’ partial Apatosaurus in Hall 38. When Edward Holt announced that he had discovered the front half of a sauropod near Green River, Utah, the Field Museum purchased the rights to excavate and display the find. Gilpin added the new fossils to the existing mount without dismantling Riggs’ heavy-duty armature. Relabeled “Brontosaurus” and erroneously given a casted Camarasaurus skull, the refreshed sauropod debuted in April 1958 – half a century after Riggs started the project.

The next three decades saw occasional piecemeal additions to the fossil halls. For example, the University of Chicago donated its entire geology collection to the Field Museum in 1965. This included a unique assortment of Permian amphibians and synapsids from the red beds of central Texas, many of them holotypes. Field Museum preparators remounted several of these specimens and integrated them into the exhibits. Nevertheless, Hall 38 never received a complete overhaul, and by the late 1980s it was quite dated. Not only were the fossil mounts in stiff, tail-dragging poses, but the stilted label copy written by curators past did not meet modern expectations for natural history exhibits. Even the vibrant Charles Knight murals looked tired behind years of accumulated dust and dirt. In short, the Field Museum was long overdue for a total re-imaging of its paleontology displays.

Next time, we’ll take a look at the Field Museum’s fossil exhibits from the 1990s onward. Stay tuned!

References

Beecher, C.E. 1901. The reconstruction of a Cretaceous dinosaur, Claosaurus annectens Marsh. Transactions of the Connecticut Academy of Arts and Sciences. 11: 311-324.

Brinkman, P.D. 2000. Establishing Vertebrate Paleontology at Chicago’s Field Colombian Museum: 1893-1898. Archives of Natural History 27: 1: 81-114.

Brinkman, P.D. 2o10. The Second Jurassic Dinosaur Rush: Museums and Paleontology in America at the Turn of the 20th Century. Chicago, IL: The University of Chicago Press.

Chicago Natural History Museum Bulletin. (March 1956). 27: 3.

Gilpin, O.L. 1959. A Freestanding Mount of Gorgosaurus. Curator 2: 2: 162-168.

Glut, D.F. 2001. Remembering the Field Museum’s Hall 38. Jurassic Classics: A Collection of Saurian Essays and Mesozoic Musings. Jefferson, NC: McFarland.

Lelièvre, M A. 2006. Evolving Planet: Constructing the Culture of Science at Chicago’s Field Museum. Anthropologica 48: 2: 293-296.

Milner, R. 2012. Charles R. Knight: The Artist Who Saw Through Time. New York, NY: Abrams.

Tubitis, T.J. 2005. Revitalizing Life Over Time: A New Look for a Very Old Topic. In the Field 76: 2: 18.

Williams, P.M. 1968. The Burham Plan and the Field Museum. Bulletin of the Field Museum of Natural History 39: 5: 8-12.

Leave a comment

Filed under dinosaurs, exhibits, FMNH, fossil mounts, history of science, mammals, museums, reptiles, sauropods

Envisioning the Ice Age at NMNH

neanderthal diorama

The neanderthal burial diorama. Image from Ice Age Mammals and the Age of Man, 1974.

On September 13, 1974, the Hall of Ice Age Mammals and the Rise of Man opened in Hall 6 at the National Museum of Natural History. Part of the “third wave” of NMNH exhibits, the Ice Age Hall was the result of interdisciplinary collaboration and a new drive to create more accessible, visitor-centric museum experiences. Specifically, the exhibit was a response to increasing pressure for museums to become destination attractions, valuing visitors’ desire to be entertained above anything else. The Ice Age Hall was meant to prove that good science and the intrinsic value of specimens could, in fact, be applied in a way that would appeal to contemporary audiences. The curators, designers, educators, and artists involved with the project saw it as an important departure from old methodologies, and expected it to be a template for future exhibits. This transition did not necessarily come easily, but for 40 years the results spoke for themselves.

The Hall of Quaternary Vertebrates

wegegeg

Large fossil mounts in the short-lived Pleistocene Hall. Images courtesy of the Smithsonian Institution Archives.

Despite the fanfare accompanying the Ice Age Hall’s opening, NMNH regulars would be forgiven for noticing that much of the exhibit looked familiar. Just four years earlier, this same space saw the opening of the brand-new Hall of Quaternary Vertebrates. This was the fifth and final phase of a thorough re-imagining of the museum’s fossil displays that began in 1959. Under the guidance of exhibit designer Ann Karras, the loose arrangement of specimens that had characterized the east wing for half a century was replaced with a directed narrative of the biological and geological history of the Earth.

This new direction was motivated by complementary revolutions in the museum field and in paleontology. Museum workers shrugged off their “cabinet of curiosity” roots and embraced education-oriented exhibits. Designers began to envision the routes visitors would travel through an exhibit space, and consider how objects on display could contribute to holistic stories. Meanwhile, paleontologists moved their field away from purely descriptive natural history, exploring instead how the fossil record could inform our understanding of evolution and ecology. At NMNH, this change in ideology inspired paleontologists to break away from the Geology Department and form their own Department of Paleobiology. The common thread between both transitions was a focus on connections – bringing new meaning and relevance to disparate parts by placing them in a common narrative.

Piano wire barely visible. Photo from Marsh 2014.

Two dire wolves posed over a horse. This display didn’t make it into the Ice Age Hall. Source

As Curator of Paleontology, C.L. Gazin oversaw most of the east wing modernization and designed the Tertiary Mammals exhibit in Hall 4 himself. Gazin retired in 1970, however, so responsibility for the unfinished Quaternary exhibit in Hall 6 went to new hire Clayton Ray, the Assistant Curator of Cenozoic Mammals. To fill out the Quaternary Hall, Ray arranged a number of trades with other museums. The Natural History Museum of Los Angeles County provided a saber toothed cat, two dire wolves, and the sheep-sized sloth Paramylodon (USNM 15164) from the La Brea tar pits, while the American Museum of Natural History was able to spare a bison “mummy” (USNM 26387) and a taxidermied musk ox. Ray also selected a complete set of mammoth bones from the AMNH collections, which were found during a gold mining operation near Fairbanks, Alaska. The bones were collected individually and belonged to an unknown number of individuals (they may well represent multiple species), but they were sufficient for preparator Leroy Glenn to construct a complete mounted skeleton.

Ray placed the new mammoth (USNM 23792) alongside the Michigan mastodon (USNM 8204), which had been on display since 1904. The mammoth was so tall that it had less than an inch of clearance with the ceiling. The other big draw in  the Quaternary Hall was a pair of never-before-exhibited giant sloths (USNM 20867 and USNM 20872) assembled from material Gazin collected in Panama. Referred to as “megatheres” at the time, these sloths are actually Eremotherium, and they are composites of at least eight individuals. The giant sloths were positioned back-to-back on a central platform, accentuated by an illuminated opening in the ceiling. All four giant mammal skeletons were supplemented with 1/5th scale life restorations created by staff artist Vernon Rickman. Exhibits specialist Lucius Lomax came up with the idea to display the fossil mounts behind piano wire, stretched from the floor to the ceiling and arranged in rows. The Eremotherium platform alone required 500 strands – or about 6000 feet – of wire.

A New Vision

Chimera mammoth

The composite mammoth looms over other specimens along the right wall of the Ice Age Hall. Photo by the author.

Neither NMNH staff nor museum visitors were overjoyed with the Quaternary Hall as it stood in 1970. The piano wire Lomax had installed was a frequent cause for complaint: visitors would constantly pluck at the strings and occasionally break them. The wires also ruined photos. Automatic lenses would focus on the wire, so when visitors got their vacation pictures developed they would end up with a bunch of images of vertical strands with darkness beyond them. Nevertheless, the piano wire was really just a scapegoat for deep-seated disagreements over content between paleontology curators and exhibit designers. This apparently unsolvable clash of personalities contributed to the hall being closed indefinitely after just a couple years.

Paleontologist Porter Kier became Director of NMNH in 1973, and one of his first moves was to assemble a new team to reinvent the Quaternary Hall. Paleobotanist Leo Hickey, geologists Robert Emery and Thomas Simkin, and anthropologist William Fitzhugh conceived of an interdisciplinary exhibit that would explore the ice ages from multiple perspectives. Continental glaciation, the evolution and extinction of large mammals, and the rise of humans would all be presented in a single, holistic story. In what was at the time a novel development, the curators worked with Elaine Anderson and other “conceptualizers/writers” from the Office of Exhibits. The scientists conceived of the main ideas and ensured factual accuracy, but the Office of Exhibits ultimately wrote the label copy and oversaw the construction of the exhibition.

arch section

A statue of an archaeologist at work was a popular part of the exhibit. Image from Ice Age Mammals and the Emergence of Man, 1974.

To accommodate new content, the existing Quaternary Hall layout had to be completely gutted and replaced. Although Clayton Ray was conspicuously absent from the exhibit team, most of the modern and fossil animal specimens he had gathered were reused in different locations. The center of the exhibit became an enclosed theater with a video presentation about the advance and retreat of North American glaciers. The north end of the hall was overtaken by human evolution displays. Replica skulls and full-body illustrations showed the progression of hominids from australopithicines to modern humans, amusingly represented by a hippie. Vernon Rickman returned to create a life-sized diorama depicting a neanderthal burial ceremony. While directly based on excavations at Regourdou Cave in France, the scene was also inspired by the much-publicized Shanidar Cave site in Iraq, where neanderthals allegedly laid their dead to rest on a bed of freshly picked flowers. Finally, a cast of an engraved mammoth tusk, based on a 25,000 year old original from the Czech Republic, was added to the south entrance. This piece was meant to tie the exhibit’s narrative together, symbolizing “man’s emergence in the ice age as a dominant influence on other animals and his environment” (Ice Age Mammals and the Emergence of Man, 1974).

Vernon Rickman works on neanderthal models in 1973. Image Courtesy of the Smithsonian Institution archives.

Vernon Rickman works on neanderthal models in 1973. Image courtesy of the Smithsonian Institution Archives.

The Ice Age Hall was completed remarkably quickly. Kier pulled the team together in early 1974 and the new displays were designed, written, and fabricated by September. At least internally, a great deal of excitement accompanied the reopening of Hall 6. The Ice Age Hall was a serious departure from how exhibit work had traditionally been done at NMNH, but it also represented an attempt by the museum to stand its ground in the face of pressure to delve into “edutainment.” This was a trial run at developing a visitor-focused but science-driven exhibit, and everyone involved was anxious to see how the public would react.

Legacy of the Exhibit

Eremotherium today. Photo by the author.

Few visitors can help but stop in their tracks at the sight of the Eremotherium pair. Photo by the author.

In 1978, Robert Wolf and Barbara Tymitz published a “naturalistic/responsive” evaluation of the Ice Age Hall. Their groundbreaking and oft-cited methodology involved interviewing visitors and surreptitiously tracking them through the gallery space, seeking to understand how museumgoers were using and interpreting the “complex set of stimuli” presented by the exhibit. This document, and especially the taxonomy of visitor types it describes, may well have influenced the museum field more than the Ice Age Hall itself.

According to Wolf and Tymitz, the Ice Age Hall was largely successful. Visitors generally remembered the major topics under discussion, and frequently left more curious about natural history than when they entered. They also noticed the difference in layout from the rest of the museum, describing it as easier to navigate and understand. Not surprisingly, the mammoth, mastodon, Eremotherium, and neanderthal burial were the most popular and most photographed objects. In comparison, the carved mammoth tusk at the front of the hall recieved surprisingly little attention. This object was intended to be tie the entire exhibit together, but most people ignored it entirely. Likewise, the separation of North and South American animals via an architectural “land bridge” was completely lost on visitors. Wolf and Tymitz observed that visitors entering from the south paid more attention to the fossil mounts, while visitors entering from the north were drawn to the glacier theater. A lesson about the importance of sight lines and traffic flow lies therein.

La brea mounts. Photo by the author.

Paramylodon and Smilodon from the La Brea tar pits. Take a good look at the sloth, because it won’t be returning in 2019. Photo by the author.

After 40 years, not every element of the Hall of Ice Age Mammals and the Emergence of Man aged gracefully. Most obviously, the androcentric title and frequent use of the word “man” to describe humans throughout the label copy comes across as painfully dated. Displays that warned of another period of global cooling were removed (or at least stopped being lit) when anthropogenic warming emerged as a crucial public policy concern. The multimedia demonstration of continental glaciation was shut down by the early 2000s, and the human evolution corner was boarded up once the Hall of Human Origins opened in 2010. While the neanderthal diorama remained on display, recent research has shown that the affectionate burial it depicts is probably a misinterpretation. Ironically, the gradual removal of geology and anthropology components effectively turned the Ice Age Hall into the straightforward menagerie of Pleistocene animals that Ray initially envisioned.

The Ice Age Hall closed along with the rest of the NMNH fossil displays in April 2014. When the east wing reopens, many of the specimens will return restored and remounted, but in a different location. Since the new National Fossil Hall will be arranged in reverse chronological order, Hall 8 itself will house displays on the origins of life and an expanded FossiLab. Still, the Ice Age Hall experiment continues to leave its mark on the museum. The collaborative workflow and sharing of responsibilities between curators, educators, and exhibit specialists pioneered in the development of this exhibit remains standard practice today. The result has been ever more effective displays, providing solid scientific content to the widest possible audience.

References

Eschelman, R.E., Emry, R.J., Domning, D.P. and Bohaska, D.J. (2002). Biography and Bibliography of Clayton Edward Ray. Cenozoic Mammals of Land and Sea: Tributes to the Career of Clayon E. Ray. Emry, R.J., ed. Washington, DC: Smithsonian Contributions to Paleobiology.

Lay, M. (2013). Major Activities of the Division of Vertebrate Paleontology During the 1960s. http://paleobiology.si.edu/history/lay1960s.html

Marsh, D.E. (2014). From Extinct Monsters to Deep Time: An ethnography of fossil exhibits production at the Smithsonian’s National Museum of Natural History. http://circle.ubc.ca/handle/2429/50177

Sepkoski, D. (2012). Rereading the Fossil Record: The Growth of Paleobiology as an Evolutionary Discipline. Chicago, IL: The University of Chicago Press.

Smithsonian Institution. (1974). Ice Age Mammals and the Emergence of Man. Washington, DC: Elephant Press.

Wolf, R.L. and Tymitz, B.L. (1978). Whatever Happened to the Giant Wombat: An Investigation of the Impact of the Ice Age Mammals and the Emergence of Man Exhibit. Washington, DC: Smithsonian Institution.

Yochelson, E. (1985). The National Museum of Natural History: 75 Years in the Natural History Building. Washington, DC: Smithsonian Institution.

4 Comments

Filed under anthropology, education, exhibits, Extinct Monsters, fossil mounts, history of science, mammals, museums, NMNH, science communication

Was the Hawkins Hadrosaurus real?

Photo from Weishampel and Young 1996.

Hadrosaurus at the Academy of Natural Sciences. Photo from Weishampel and Young 1996.

In the “Claosaurus” post earlier this week, I temporarily(?) lost my mind when I said that the Hadrosaurus Benjamin Waterhouse Hawkins assembled for the Academy of Natural Sciences was 100% plaster reconstruction. Thanks to John Sime, among others, for pointing out that this was incorrect. As usual, the truth is more complicated, and therefore much more interesting.

The Hadrosaurus project began when Hakwins was commissioned to create a series of life-sized prehistoric animals for display in New York City’s central park, under the direction of Joseph Leidy. The exhibition was cancelled when Hawkins’ on-site workshop was burned down by vandals, but he was able to salvage the Hadrosaurus skeleton for display at the Academy in Philadelphia. This reconstruction was based on little more than two limbs and a handful of vertebrae. It was a well-reasoned attempt – and it drew huge crowds – but it wasn’t long before new dinosaur finds rendered it obsolete. In 1901, Charles Beecher wrote that the Hadrosaurus mount had “long since ceased to have any value or interest except as a historical attempt.” No longer considered informative, the original Hadrosaurus was probably dismantled around the start of the 20th century. At least three plaster copies were distributed to other museums, but these were also discarded long ago.

There is no question that Hawkins’ reconstruction doesn’t reflect our present understanding of this animal, so in that sense it isn’t “real.” Still, it is of historic interest whether Hawkins used the handful of original Hadrosaurus fossils in the mount itself, or whether the entire display was fabricated. There is precedent for both posibilities: John Peale mounted an original mastodon skeleton in 1802, but the Smithsonian’s first attempts at Basilosaurus and Triceratops (1895 and 1900 respectively) included no real fossils. This question was actually up for discussion as early as 1926. Responding to an inquiry from Peabody Museum paleontologist Richard Lull, Academy of Natural Sciences curator Witmer Stone wrote that the Hadrosaurus mount was a complete reproduction. When Lull followed up with William Matthew of the American Museum of Natural History, however, Matthew recalled that “some or all of the original bones were used.”

The two letters reproduced below are in the collection of the Department of Vertebrate Paleontology Archives at the Peabody Museum of Natural History, and are shared with permission.

courtesy

Letter from Witmer Stone to Richard Lull, January 26, 1925. Courtesy of the Dept. of Vertebrate Paleontology Archives, Yale Peabody Museum of Natural History.

Courtesy

Letter from William Matthew to Richard Lull, January 30, 1925. Courtesy of the Dept. of Vertebrate Paleontology Archives, Yale Peabody Museum of Natural History.

A look at the original Hadrosaurus fossils, now cataloged as ANSP 10005, suggests that Matthew was correct. At least a couple of the bones appear to bear drill holes, a tell-tale sign that they were once fastened to an armature. Likewise, in a photograph of the mount in Hawkins workshop, the elements that were actually recovered – the left leg*, part of the pelvis, and a scattering of vertebrae – appear to be darker in color. This suggests that these are the real bones, and the rest of the skeleton is plaster…unless Hawkins painted plaster casts to demonstrate which elements had been found.

*Note that the image below has been flipped horizontally for some reason. In the original, the left side of the skeleton is facing the camera.

Hawkin's studio

Hadrosaurus in Hawkins’ studio. Image from Carpenter et al. 1994.

The answer to this little conundrum can be found in the official guidebook to the Academy of Natural Sciences, published in 1879. Apparently there were two versions of Hadrosaurus on display. The original 1868 mount did include the original fossils, but when the museum moved to a larger facility in 1876 (in part because of the spike in visitation caused by the Hadrosaurus exhibit) the mount was remade. The bones were not faring well in open air and were rapidly deteriorating, so they were retired to the collections and replaced with casts. Anyone who saw the Hadrosaurus before 1876 saw the fossils incorporated into the mount, and anyone who visited later saw a complete facsimile. Still, I’m pretty sure William Matthew was remembering incorrectly. He was born in 1871, so unless he was carefully observing the composition of the mount at age 5, he shouldn’t have seen the original version!

References

Beecher, C.E. 1901. The reconstruction of a Cretaceous dinosaur, Claosaurus annectens Marsh. Transactions of the Connecticut Academy of Arts and Sciences. Vol. 11, pp. 311-324.

Carpenter, K., Madsen, J.H. and Lewis, L. 1994. Mounting of Fossil Vertebrate Skeletons. Vertebrate Paleontological Techniques, Vol. 1. Cambridge, UK: Cambridge University Press.

Prieto-Márquez, A., Weishampel D.B., and Horner J.R. 2006. The dinosaur Hadrosaurus foulkii, from the Campanian of the East Coast of North America, with a re-evaluation of the genus. Acta Palaeontologica Polonica. Vol. 51, pp. 77-98.
Ruschenberger, W.S.W. and Tryon, G.W. 1879. Guide to the Museum of the Academy of Natural Sciences of Philadelphia. Philadelphia, PA: Academy of Natural Sciences.
Weishampel. D.B. and Young, L. 1996. Dinosaurs of the East Coast. Baltimore, MD: The Johns Hopkins University Press.

Leave a comment

Filed under dinosaurs, fossil mounts, history of science, museums, ornithopods

Beecher’s “Claosaurus”

Readers are likely aware that the Hadrosaurus Benjamin Waterhouse Hawkins created for the Academy of Natural Sciences was the first mounted dinosaur skeleton. It is less widely known, however, that this Hadrosaurus was a plaster facsimile, which included none of the actual fossils that inspired it. (edit: not quite, see comments). The title of first dinosaur mount composed of original fossils belongs to the Belgian Iguanodon assembled by Louis Dollo in 1891 (I should probably write about this eventually, but Fernanda Castano has an excellent account at Letters From Gondwana). So what was the first real fossil dinosaur mount on this side of the Atlantic? Glad you asked – that would be none other than the 1901 Edmontosaurus at the Peabody Museum of Natural History.

Edmontosaurus is surprisingly modern

The PMNH Edmontosaurus with Deinonychus and Centrosaurus. Photo by the author.

There are plenty of Edmontosaurus skeletons on display today, but the Yale mount is noteworthy because of its remarkably modern appearance. While the Hawkins Hadrosaurus and Dollo Iguanodon were upright tail-draggers, the Edmontosaurus could be mistaken for a mount constructed in the last quarter century. Its raised tail, horizontal posture, and energetic gait all reflect current thinking about dinosaur posture and locomotion. And yet, it was built at the turn of the century, back when paleontologists supposedly all thought of dinosaurs as lethargic lizards.

The Hawkins Hadrosarus and Dollo Iguanodon. Photos from

The Hawkins Hadrosarus and Dollo Iguanodon. Images from Paper Dinosaurs.

The scientist behind this mount was Charles Beecher. Born in Pennsylvania, Beecher studied at the University of Michigan before taking an Assistant of Paleontology position at Yale in 1888. He completed his PhD under Marsh, who apparently thought highly of him (and Marsh didn’t think highly of many people). Although his preferred research subjects were Paleozoic invertebrates, Beecher could be counted on to help prepare his mentor’s vast collection of dinosaur fossils, when needed. When Marsh died in 1899, Beecher succeeded him as the head of the Peabody Museum, and set himself the task of mounting one of the institution’s best dinosaur specimens for display.

Beecher selected YPM VP 2182 as the Peabody Museum’s first fossil mount because it was nearly complete and mostly articulated. Known to Marsh and Beecher as “Claosaurus” annectens*, this Edmontosaurus skeleton was collected in Wyoming by John Bell Hatcher (because of course it was). Beecher and assisting preparator Hugh Gibb attempted to preserve the fossils within their original matrix as much as possible. Since the specimen was somewhat laterally compressed, Beecher kept the right side mostly in situ and built up the left in high relief. The head and neck were technically never removed from their matrix block, but since the head was found curved under the body it had to be rotated into its life position. All told, only the right ribs, the corocoids, the final two-thirds of the tail, and some of the vertebral processes were reconstructed. No attempt was made to restore the ossified dorsal tendons, which were poorly preserved on this specimen.

woo

Beecher’s Edmontosaurus, ca. 1917. Source

The complete mount is 13 feet tall and 29 feet long, its tail extending past the edge of the 27 foot slab. For a few years, it was the largest fossil mount ever built. The slab itself is made up of original matrix blocks sealed together with a manufactured surface created from plaster, resin, and ground Laramie Formation sandstone. It was assembled in four pieces secured to wooden frames. These were designed to be separated and moved with relative ease, although PMNH staff have yet to try.

According to Beecher, he imbued the Edmontosaurus with its lively pose in order to preserve the in situ orientation of the pelvis and left femur. It is worth quoting Beecher’s 1901 description of the mount in full:

“It is intended that this huge specimen should convey to the observer the impression of the rapid rush of a Mesozoic brute. The head is thrown up and turned outward. The jaws are slightly separated. The forearms are balancing the sway of the shoulders. The left hind leg is at the end of the forward stride and bears the entire weight of the animal. The right foot has completed a step and has just left the ground preparatory to the forward swing. The ponderous and powerful tail is lifted free and doubly curved so as to balance the weight and compensate for the swaying of the body and legs. The whole expression is one of action and the spectator with little effort may endow this creature with many of its living attributes.”

Much like the AMNH Gorgosaurus, the Yale Edmontosaurus demonstrates that early 20th century paleontologists’ supposed aversion to energetic and agile dinosaurs has been grossly overstated. Beecher saw Edmontosaurus as a powerful, active animal, and actually criticized the earlier reconstructions by Hawkins and Dollo. He correctly pointed out that the back-swept ischia of ornithopod dinosaurs would not allow room for the drooping tails they had reconstructed, and also noted that fossilized dinosaur trackways never show the mark of a dragging tail.

In the great hall of dinosaurs

Edmontosaurus as presently displayed in the Great Hall of Dinosaurs. Source

Beecher died suddenly in January of 1904, and the Edmontosaurus display ended up being one of his final professional accomplishments. Despite the relative dearth of dinosaur material available at the time, Beecher’s careful and impartial study of the available evidence allowed him to reconstruct this animal in a way that is still considered accurate 114 years later. Beecher’s work shows us that old research isn’t necessarily outmoded. Good science can come from any age and any source, if one only takes the time to look.

*Today, the genus Claosaurus is reserved for Claosaurus agilis from Kansas. The referred species annectens has since been placed in Thespesius, Trachodon, Anatosaurus, and now Edmontosaurus.

References

Beecher, C.E. 1901. The reconstruction of a Cretaceous dinosaur, Claosaurus annectens Marsh. Transactions of the Connecticut Academy of Arts and Sciences. Vol. 11, pp. 311-324.

Jackson, R.T. 1904. Charles Emerson Beecher. The American Naturalist. Vol 38, No. 450.

Marsh, Othniel C. 1892. Restorations of Claosaurus and Ceratosaurus. American Journal of Science. Vol. 44, pp. 343-349.

5 Comments

Filed under dinosaurs, fossil mounts, history of science, museums, ornithopods, PMNH, reptiles

AMNH 5027 at 100

In December 1915, the American Museum of Natural History unveiled the very first mounted Tyrannosaurus rex skeleton, irrevocably cementing the image of the towering reptilian carnivore in the popular psyche. For a generation, AMNH was the only place in the world where one could see T. rex in person. Despite the tyrant king’s fame, old books emphasize the rarity of its fossils. The situation is very different today. In the last 30 years, the number of known Tyrannosaurus specimens has exploded. Once elusive, T. rex is now one of the best known meat-eating dinosaurs, and real and replica skeletons can be seen in museums around the world. The AMNH mount is no longer the only T. rex around, nor is it the biggest or most complete. It was, however, the first, and in a few weeks it will mark the 100th anniversary of its second life. Below is a partially recycled recap of this mount’s extraordinary journey.

Photo by the author.

AMNH 5027 in November 2015. Photo by the author.

The mount known as AMNH 5027 is actually a composite of material from two individuals. The first is the Tyrannosaurus rex holotype (originally AMNH 973, now CM 9380), which was discovered by Barnum Brown and Richard Lull during an AMNH expedition to Montana in 1902. The find consisted of little more than the pelvis, a single femur, one arm and shoulder, and fragmentary portions of the jaw and skull. Nevertheless, this was enough for AMNH director Henry Osborn to publish a brief description in 1905, as well as coin the species’ brilliantly evocative name. That same year, Adam Hermann prepared a plaster replica of the animal’s legs and pelvis, using Allosaurus fossils as reference when sculpting the missing lower legs and feet. This partial mount was initially displayed alongside the skeleton of a large ground bird, in order to accentuate the anatomical similarities.

Brown located a better Tyrannosaurus specimen in 1908. Apparently fearing poaching or scooping, Osborn wrote to Brown that he wished to “keep very quiet about this discovery, because I do not want to see a rush into the country where you are working.” After vanquishing many tons of horrific sandstone overburden, Brown returned to New York with what was at the time the most complete theropod specimen ever found. In addition to an “absolutely perfect” skull, the new find included most of the rib cage and spinal column, including the first half of the tail (Osborn 1916). Lowell Dingus would later describe this second specimen (the true AMNH 5027) as “a nasty old codger”, suffering from severe arthritis and possibly bone cancer. These pathologies were undoubtedly painful and probably debilitating.

Model of unrealized T. rex showdown mount from Osborn 1913.

Model of the unrealized T. rex showdown mount from Osborn 1913.

Osborn initially wanted to mount both Tyrannosaurus specimens facing off over a dead hadrosaur. He even commissioned E.S. Christman to sculpt wooden models which which to plan the scene (shown above). However, the structural limitations inherent to securing heavy fossils to a steel armature, as well as the inadequate amount of Tyrannosaurus fossils available, made such a sensational display impossible to achieve. Instead, the available fossils complemented one another remarkably well in the construction of a single mounted skeleton. Osborn noted this good fortune in 1916, but his statement that the two specimens were “exactly the same size” wasn’t quite accurate. The holotype is actually slightly larger and more robust than the 1908 specimen, and to this day the AMNH Tyrannosaurus mount has oversized legs.

The original Tyrannosaurus rex mount at the American Museum of Natural History. Photo from Dingus 1996.

The original Tyrannosaurus rex mount at AMNH. Note the original 1905 replica legs in the background. Photo from Dingus 1996.

Instead, Hermann’s team prepared a single Tyrannosaurus mount, combining the 1908 specimen with the reconstructed pelvis and legs based on the 1905 holotype. When the completed mount was unveiled in 1915, the media briefly lost their minds. In contemporary newspapers, the skeleton was called “the head of animal creation”, “the prize fighter of antiquity”, and “the absolute warlord of the earth”, among similarly hyperbolic proclamations. Even Osborn got in on the game, calling Tyrannosaurus “the most superb carnivorous mechanism among the terrestrial Vertebrata, in which raptorial destructive power and speed are combined.” With its tooth-laden jaws agape and a long, dragging lizard tail extending its length to over 40 feet, the Tyrannosaurus was akin to a mythical dragon, an impossible monster from a primordial world. This dragon, however, was real, albeit safely dead for 66 million years.

Image courtesy of the AMNH Archives.

T. rex in the Cretaceous Hall, 1960. Image courtesy of the AMNH Research Library.

The AMNH’s claim to the world’s only mounted Tyrannosaurus skeleton ended in 1941, when the holotype was sold to the Carnegie Museum of Natural History. The Pittsburgh museum’s hunch-backed reconstruction of the tyrant king was on display within a year. Although no longer the only T. rex on display, the AMNH mount certainly remained the most viewed as the 20th century progressed. It became an immutable symbol for the institution, visited again and again by generations of museum goers. Its likeness was even used as the iconic cover art of Michael Crichton’s Jurassic Park.

By the 1980s, however, a new wave of dinosaur research had conclusively demonstrated that these animals had been active and socially sophisticated. The AMNH fossil galleries had not been updated since the 1960s, and the upright, tail-dragging T. rex in particular was painfully outdated. AMNH had once been the center of American paleontology, but now its displays were lagging far behind newer museums.

finished mount, room under construction

Restoration of AMNH 5027 was completed nearly three years before the hall reopened. Photo from Dingus 1996.

Between 1987 and 1995, Lowell Dingus coordinated a comprehensive, $44 million renovation of the AMNH fossil exhibits. As part of the project, chief preparator Jeanne Kelly led the restoration and remounting of the most iconic specimens, Apatosaurus and Tyrannosaurus. Of the two mounts, the Tyrannosaurus presented the bigger challenge. The fossils were especially fragile, and some elements, specifically the cervical vertebrae, had never been completely freed from the sandstone matrix. It took six people working for two months just to strip away the layers of shellac applied by the original preparators. All told, the team spent a year and a half dismantling, conserving, and rebuilding the T. rex.

Phil Fraley’s exhibit company constructed the new armature, which gave the tyrant king a more accurate horizontal posture. While the original mount was supported by obtrusive rods extending from the floor, the new version is actually suspended from the ceiling by a pair of barely-visible steel cables. Playing with Christman’s original wooden models, curators Gene Gaffney and Mark Norrell settled on a fairly conservative stalking pose, imbuing the mount with a level of dignity befitting this historic specimen. The restored AMNH 5027 was completed in 1992, but would not be unveiled to the public until the rest of the gallery was finished in 1995. Since that time, tens of millions of visitors have flocked to see this new interpretation of Tyrannosaurus. This is the skeleton that showed the world that dragons are real, and it is still holding court today.

References

Dingus, L. 1996. Next of Kin: Great Fossils at the American Museum of Natural History. New York, NY: Rizzoli International Publications, Inc.

Glut, D.F. 2008. Tyrannosaurus rex: A Century of Celebrity. Tyrannosaurus rex, The Tyrant King. Larson, Peter and Carpenter, Kenneth, eds. Bloomington, IN: Indiana University Press.

McGinnis, H.J. 1982. Carnegie’s Dinosaurs: A Comprehensive Guide to Dinosaur Hall at Carnegie Museum of Natural History, Carnegie Institute. Pittsburgh, PA: The Board of Trustees, Carnegie Institute.

Norell, M, Gaffney, E, and Dingus, L. 1995. Discovering Dinosaurs in the American Museum of Natural History. New York, NY: Alfred A. Knopf, Inc.

Osborn, H.F. 1906. Tyrannosaurus, Upper Cretaceous Carnivorous Dinosaur: Second Communication. Bulletin of the American Museum of Natural History vol. 22, pp. 281-296.

Osborn, H.F. 1913. Tyrannosaurus, Restoration and Model of the Skeleton. Bulletin of the American Museum of Natural History vol 32, pp. 9-12.

Osborn, H.F. 1916. Skeletal Adaptations of Ornitholestes, Struthiomimus, and TyrannosaurusBulletin of the American Museum of Natural History vol 35, pp. 733-771.

5 Comments

Filed under AMNH, dinosaurs, fossil mounts, history of science, museums, theropods

The Pan-American Expo Triceratops Lives On UPDATE: Or does it?

Triceratops at the Natural History Museum, London.

Triceratops at the Natural History Museum, London. Source

Don’t you hate it when you miss something glaringly obvious? I’ve never seen the Triceratops skeleton at London’s Natural History Museum in person, but I’ve seen enough pictures to know that it’s a little weird. Inaccuracies like the columnar feet, dragging tail, and vertical forelimbs can be attributed the display’s age, but the head doesn’t really look like any other Triceratops skull that’s ever been found. I had assumed that the funky frill and extremely long nasal horn were sculpted flourishes, but it turns out that no part of this Triceratops is real. It’s not a heavily-reconstructed original skeleton or even a cast – it’s a papier mâché model. And not just any model, but one that I’ve already written about in a different context.

Pan American exhibition

The Lucas Triceratops model at the 1901 Pan-American Exhibition. Source

Frederic Lucas, an Assistant Curator at the United States National Museum, created this Triceratops in 1900 for the Smithsonian display at the Pan-American Exhibition in Buffalo, New York. A mix of corporate and government displays based around the themes of peace, prosperity, and technology, the Pan-American Exhibition lasted from May to November 1901 (it was cut short when President William McKinley was shot on the fairgrounds). The Smithsonian’s 7,500 square foot exhibit took nearly a year to prepare, and showcased specimens from all departments of the nascent institution. Indeed, the Smithsonian’s participation in this and other fairs around the turn of the century is significant because these attractions were the basis for the some of the first exhibits at the USNM. Displays initially created for fairs often found a home in the museum’s permanent galleries, and the fair exhibitions were generally used as a template for the first generation of Smithsonian exhibits.

The Triceratops model was meant to represent the glut of fossils from the western United States that the Smithsonian had recently acquired from O.C. Marsh. Perhaps because most of those specimens were still unpacked and unprepared (the USNM didn’t hire a dedicated fossil preparator until 1903), Lucas sculpted the skeleton freehand based on one of Marsh’s published illustrations. It’s noteworthy that Lucas was not a paleontologist – he was brought on board at the age of 21 with no formal training because of his talent for constructing taxidermy displays. At any rate, Lucas followed Marsh’s reconstruction – at the time the only Triceratops reconstruction available – religiously when constructing his full-sized model.

St. Louis Expo

The Lucas Triceratops at the Louisiana Purchase Exposition in 1904. Source

After the Pan-American Exhibition, Lucas’s Triceratops made a second appearance at the 1904 Louisiana Purchase Exposition in St. Louis, Missouri. It was rendered obsolete shortly thereafter when Charles Gilmore assembled the world’s first real Triceratops skeleton at the USNM. As I’ve covered before, the act of physically manipulating the Triceratops fossils into a standing mount showed Gilmore that Marsh’s straight-legged reconstruction was a physical impossibility.

My understanding was that the Lucas model was lost or destroyed shortly after Gilmore’s real Triceratops went on display in 1905. I should have been more skeptical, however, because exhibits like this are almost never wasted. For example, Gilmore reported in 1943 that the Hadrosaurus cast displayed at the USNM before his arrival had been discarded due to wear and tear, but the mount had actually been given to the Field Museum in the 1890s. A couple months ago, I found out that Albert Koch’s chimeric mastodon (what he called “Missourium”) was purchased by Richard Owen on behalf of the British Museum and remounted. And just this year, the Smithsonian’s 112 year-old Stegosaurus model began a new life at the Museum of the Earth in Ithaca, New York.

tweet

Hey, that looks familiar! Source

The above tweet from the London Natural History Museum finally clued me in that the Lucas Triceratops had been hiding in plain sight for more than a century. The NHM (then the British Museum) received their Triceratops from the Smithsonian in 1907 (confirmed in the July 1907 issue of The Museums Journal), just when the Smithsonian had an extra Triceratops on hand. The London model is plainly not a cast of Gilmore’s 1905 mount, but it does resemble the Lucas model in most every detail, from the way the legs are posed to the exaggerated horns and frill. The only clear difference I can see is in the position of the head, which is much more elevated in the photos from the Buffalo and St. Louis expositions. However, I imagine the model would have been partially disassembled for transport. Perhaps when it was rebuilt in London the head ended up lower, whether by accident or design.

Unless there’s reason to think there were two copies of the Lucas Triceratops, I’d say the most parsimonious conclusion is that the London Triceratops is the very same model that was first displayed at the Pan-American Exhibition in 1901. Much like it’s long-time companion Dippy the Diplodocus, this Triceratops model is a century-old historic icon, one that has introduced generations upon generations of visitors to the enormity of deep time and the wonders of our prehistoric past. Inaccurate sculpture or not, it’s definitely something to preserve and to celebrate.

UPDATE: Shortly after I finished this post, @NHM_London responded to my inquiry with the following:

Hmm

Did I speak too soon? Source

I’m dubious that the NHM Triceratops is a copy of Gilmore’s 1905 version, but hey, it *is* their museum. I’ll leave this post up for now and follow up when I find out more. I love a good museum mystery!

References

Gilmore C.W. (1905).The Mounted Skeleton of Triceratops prorsus. Proceedings of the U.S. National Museum 29:1426:433-435.

Gilmore, C.W. (1941). A History of the Division of Vertebrate Paleontology in the United States National Museum. Proceedings of the United States National Museum 90.

Howarth, E., Rowley, F.R., Ruskin Butterfield, W., and Madeley, C. (1908). The Museums Journal, Volume 7. Museums Association.

6 Comments

Filed under dinosaurs, fossil mounts, history of science, marginocephalians, museums, NHM, NMNH
